LC APC Steel Tube Fiber Optic PLC Splitter 1x4 Loss For PON

Product Categories
Wuhan Geehe Optical Communication Co.,ltd
Contact Now

LC APC Steel Tube Fiber Optic PLC Splitter 1x4 Loss For PON

  • 1
  • 2
  • 3

Brand Name : Geehe Comm (OEM&ODM)

Model Number : GH-PLC-1X4 -001

Certification : ISO9001:2015, RoHs, UL,CE

Place of Origin : Wuhan, China

MOQ : 1 pcs

Price : Negotiation

Payment Terms : T/T, L/C, D/P, , D/A, Western Union, MoneyGram, Sinosure

Supply Ability : 6,600 Pcs/day

Delivery Time : 7-9 working days after confirm PI TODAY

Packaging Details : Plastic box per pc with Pressure defense sponge, outer carton

Model Name : Fiber Optic PLC Splitter 1x4

Cable Type : 9/125um single-mode

PLC Casing Type : Micro PLC

Splitting Ratio : 1x4

Cable Diameter : 900um

Fiber Length : Customized Length1M, 1.5M, 2M, 2.5M, custom

Fiber Type : G657 Grade A Optical

Port Wavelength : 1310-1550nm

Package : Steel Tube, ABS Black Box, Rack, Module

Length : 1m Or 1.5m

Contact Now

LC APC Steel Tube Fiber Optic PLC Splitter 1x4 Loss For PON







Quick Overview:



  • PLC-1 × 4 -E-SM-SC/APC
  • Fiber Optic Splitter, Tube Type, PLC
  • Connector Type: SC/APC
  • Split Type: 2xN
  • Single Mode
  • Fiber:0.9mm bare fiber
  • Package: Wooden box with the designed inside box
  • Easy Installation
  • GR-1209/1220-Core Standard



Geehe Communication produces a wide range of high-performance PLC Splitters that are Telcordia GR-1209 & GR-1221 qualified
Our splitter modules have a compact package size, featuring low Insertion Loss, with a low Polarization dependent loss.

Available with 1 x 2 up to 1 x 64 and 2 x 2 up to 2 x 32 channel configurations.


These splitters are available in tube or cassette modules and can be fitted with any connector to order.







LC APC Steel Tube Fiber Optic PLC Splitter 1x4 Loss For PON





 PLC Splitter Features&Benefit:



  • Fibers are designated by labeling
  • Improves and simplifies fiber routing
  • PLC Splitters are Telcordia GR-1221-CORE and GR-1209-CORE tested
  • Low insertion loss and reflentance
  • Solution-based engineering support to meet all FTTx networking requirements
  • Universal solution



Application&Standard:



  • FTTx Deployments(GPON/BPON/EPON)
  • Cable television (CATV)
  • Local area networks (LAN)
  • Test equipment
  • Passive optical networks(PON)



LC APC Steel Tube Fiber Optic PLC Splitter 1x4 Loss For PON



Specification& parameters



Parameter 1x4 1x8 1x16 1x32 1x64 2x4 2x8 2x16 2x32
Operating Wavelength(nm) 1260~1650
Port Wavelength Range (nm) 1310 ±20,1490 ±10 and 1550 ±20
Insertion Loss @1310nm/1550nm 7.1 10.5 13.6 16.8 20.5 7.4 10.8 14.5 17.5
Uniformity (dB) 0.5 0.8 1 1.2 1.8 1.2 1.5 1.8 2
PDL @ 1310/1550 nm (dB) ≤0.3
Return Loss@ 1310/1551 nm (dB) ≤-55
Input Power (mW) 250max
Operating Temperature (℃) -40~+85℃
Storage Temperature (℃) -40~+85℃
Fiber Type Corning G657A1





PLC Splitter Package Dimensions:



WxHxD(mm) Port
60x7x4 1x4 1x8 2x4 2x8
60x12x4 1x16 2x16
80x12x6 1x32 2x32
100x40x6 1x64





Ordering Information:





PLC AAA B CC D EE FF GG
  104=1x4 108=1x8 …… 164=1x64 204=2x4 …… 232=2x32 1=900µm loose 05=0.5m 10=1.0m 15=1.5m 20=2.5m 1=900µm loose 05=0.5m 10=1.0m 15=1.5m 20=2.5m SA=SC/APC SU=SC/UPC LA=LC/APC LC=LC/UPC 00:No connector SA=SC/APC SU=SC/UPC LA=LC/APC LC=LC/UPC 00:No connector
  Configuration Input Fiber Type Input Fiber Length Output Fiber Length Output Fiber Input Connector Output Connector





Geehe Comm Service:



  • Provide the highest quality of products
  • Continuous improvement; accepting new challenges
  • Innovating new processes, and creating new products for the benefit of our customers
  • Consultative service and strive to ensure a positive and productive experience
  • Efficient use of all transportation modes and transit times
  • Greater visibility and real-time information
  • Younger team with more energy to supply VIP service for every customer
  • 24/7 service line:+86 13429864799
  • Fast turnover and delivery for orders with familiar and mature workers





LC APC Steel Tube Fiber Optic PLC Splitter 1x4 Loss For PON
